LCD Display Code Screen Instrument Color Background Segment Code For Water Heater
Model NO.: RXD-130
Widescreen: Not Widescreen
Response Time: 10ms
3D: Not 3D
Description
| Brand Name | Risenta |
| Model Number | Risenta-130 |
| Screen size | 64(W)*41(H)*9(D) mm |
| Module Size | 76(W)x58(H)x19.7(D) mm |
| Screen segment | Segment Custom LCD |
| Control/drive IC | HT1621 |
| Display color/BL LED | WHITE /BLUE/ RED /YELLOW /GREEN /RGB FULL COLLOR |
| Viewing Angle | 6 O' clock LCD LED SCREEN |
| Display mode | TN HTN positive transmissive |
| LCD parameter | duty1/4 bias1/3 |
| LCD parameter | BL I=30MA |
| LCD parameter | VOP=4.2V |
| Operating Temperature | -10~+60℃ |
| View Area | 40.5 * 20.1mm |
LCD display code screen instrument color background segment code for water heaterQuick Details
T
ype:Customized according to drawings segment lcd Display
Display Size:2.6 inch
Place of Origin:Guangdong, China
Product Name:Inverter LCD Screens
Screen size:64(W)*41(H)*9(D) mm
Module Size:76(W)x58(H)x19.7(D) mm
Screen segment:Custom LCD
Control/drive IC:HT1621
Display color/BL LED:Customized according to drawings
Viewing Angle:6 O' clock
Display mode:HTN positive transmissive
LCD parameter:duty1/4 bias1/3 VOP4.2V BL30MA
Operating Temperature:-10~+60℃
