PIN Display 2.8'' Inch TFT LCD Color Monitor

PIN Display 2.8'' Inch TFT LCD Color Monitor Quick Details

Display Ratio:16:9

Series:For Business

Aspect Ratio:16:9

Screen Type:LCD

Pixel Pitch:0.12445mm, 0.153x0.153

Horizontal Viewing Angle:160°

Built-in Speaker:No

Vertical Viewing Angle:90°

Application:LAPTOP

Response Time:2ms

Brightness:250cd/m

Interface Type:SPI

Contrast Ratio:400:1

Panel Type:TFT

Brand Name:RXD

Place of Origin:Guangdong, China

Feature:Full Color

Resolution:240x320

Active Area:36.72x48.96

Panel Size:42.72x60.26x2.30

LCD Type:TFT Negative Transmissive

Pins:18P

Operating Temperature:-20~70℃

Storage temperature:-30~80℃

Certification:RoHS

PIN Display 2.8'' Inch TFT LCD Color MonitorDiagonal Screen Size 2.8inch

Model number RXD-084

Resolutions

240x320

Outline dimension 42.72x60.26x2.30mm

Active area 36.72x48.96mm

Pixel Pitch 0.153x0.153mm

Driver IC ILI9341V

Voltage 3-5V

Operating temperature -20~70℃

Storge Temperature -30~80℃

Assemble Soldering

Pins 18P
