Inch Custom Brightness TFT LCD Screen
Type: TN
Display Size: 1-10 inch
Place of Origin: Guangdong, China
Brand Name: RXD
Description
inch Custom Brightness TFT LCD Screen Quick Details
Type:TFT,
Display Size:customize
Supplier Type:factory
Place of Origin: China
Brand Name:Risenta
Display size:customize
Resolution:800(RGB)x600 [SVGA]
Interface Type:20 pins LVDS (1 ch, 6/8-bit) , Connector
Brightness:350cd/m2
Contrast Ratio:600:1
View angle:80/80/80/80 (Typ.)(CR≥10) Left/Right/Up/ Down
Operate temperature:-20~70 (°C)
Backlight:WLED [8S4P] , 50K hours , With LED Driver
Work Mode:TN, Normally White, Transmissive
Manufacturer | |
Model Name | |
Screen Size | |
Screen Type | a-Si TFT-LCD, LCM |
Pixel Number | 800(RGB)×600 [SVGA] |
Arrangement | RGB Vertical Stripe |
Active Area(mm) | 170.4(H)×127.8(V) mm |
Outline(mm) | 203(H)×142.5(V) ×6.2(D) mm |
Bezel Area(mm) | 173.4(H)×131.2(V) mm |
Surface | Antiglare, Hard coating (3H) |
Brightness | 350 cd/m² (Typ.) |
Contrast Ratio | 600:1 (Typ.) (TM) |
Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) Left/Right/Up/ Down |
Response | 16 (Typ.)(Tr+Td) |
Good View at | 12 o'clock |
Work Mode | TN, Normally White, Transmissive |
Color Depth | 262K/16.7M 45% (CIE1931) |
Backlight | WLED [8S4P] , 50K hours , With LED Driver |
Net Weight | 200/220g (Typ./Max.) |
Used for | Industrial Application |
operating frequency | 60Hz |
Touchscreen | without |
Interface Type | 20 pins LVDS (1 ch, 6/8-bit) , Connector |
Voltage Supply | 3.3V (Typ.) |
Max. Ratings | Storage Temperature: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
RoHS Compliance | RoHS Compliance |
Aspect Ratio | 4:3 (H:V) |
Package | Original package; 40 pcs / box |
